Link Propeties

On the screen below, you can see the attributes relevant to the link behavior of that need to be informed.

Link properties Interface. Link properties Interface.

  • Link Operation Mode :
    • Open in the same Window : Displays the Form in the same browser window.
    • Open in another Window : Displays the Form in another window of the browser.
    • Open in Iframe : The Form will be displayed in the same window, allowing to position below, above, to the left or right of the Grid.
    • Open in Parent : If the Grid is in a iframe, it displays the Form in the page’s parent view port.
    • Modal : Opens the Form in modal, allowing to configure the modal size.
  • Display button (new row) on the grid toolbar : This option, when enabled, adds a button to the toolbar that allows to add a New Record to the Form.
  • Label for the button New : You can apply a Label for the button, if not informed the label will be “New”.
  • Hint for the button New : You can apply a Hint for the button, if not informed the hint will be “New”.
  • Hotkey for the button “New” : Indicates which key will be the shortcut for the New Record.

  • Exit URL for the target application : The URL that is going to call after exiting the Form. In case no value is informed, the “back” button will redirect to the Grid.

  • Form Property

    Allows to select the buttons that are going to be displayed in the Form through the link. Form properties configurations Interface. Form properties configurations Interface.

    • Enable insert button on target application : Enables the Insert Button in the Form.
    • Enable update button on target application : Enables the Update Button in the Form.
    • Enable delete button on target application : Enables the Delete Button in the Form.
    • Enable navigation button on target application : Enables the navigation buttons (first, previous, next and last) in the Form.
    • Enable button to edit a grid record : Enables the edit button for each record.
  • Iframe properties

    These options are displayed when the property Link Operation Mode is set to “Open in Iframe”. Iframe properties configurations Interface. Iframe properties configurations Interface.

    • Display the header of the called application : Displays the Form’s header.
    • Iframe position relative to the main application : It can be: below, above, right or left.
    • Action After Insert view the list below :
      • Reload Grid : Does a refresh on the current page.
      • Move to the end of the grid : Navigate to the Grid’s last page.
    • Iframe height : Iframe Height in pixels.
    • Iframe width : Iframe Width in pixels.
